Two-way Disc Plough

Two-way Disc Plough

Two-way light-duty disc plow not only has the operating performance of ordinary disc plows, but also has the unique bidirectional design advantage.
Send Inquiry
Description

Two-way light -duty Disc plow description



Two-way light-duty disc plow not only has the operating performance of ordinary disc plows, but also has the unique bidirectional design advantage. Through the horizontal swing mechanism, the bidirectional disc plow can realize bidirectional tillage, greatly reducing the turning time at the head of the field. Bidirectional alternating tillage avoids the repeated formation of furrows by one-way plows, and the ground is smoother after plowing. Therefore, the bidirectional disc plow has higher production efficiency and is more fuel-efficient. The bidirectional disc plow is an ideal tool for improving the quality and efficiency of tillage under complex soil conditions. It is mainly suitable for tillage operations of cultivated land and uncultivated land in dryland areas, especially for operations in terraced land and small cultivated areas.



Luyuan Two-way light-duty disc plow can adapt to complex soil conditions and has strong adaptability to hard, heavy, weedy, rocky or rhizome soils. It has outstanding ability to cut grass roots and crop residues and is not easy to get clogged or entangled. The design of the disc of the bidirectional disc plow rolling into the soil significantly reduces traction resistance and has low operating energy consumption. The soil is easier to break after rising and turning along the concave surface of the disc, which is conducive to subsequent sowing operations. The disc blade does not need to be frequently sharpened or replaced, which has low maintenance costs and avoids the formation of a solid plow bottom.



Luyuan Two-way light-duty disc plow is compact and lightweight, which greatly reduces the load on the tractor. It has good tillage depth stability and can maintain a consistent tillage depth, which is especially suitable for preventing moisture loss in dry land or preventing salt return in saline-alkali land.



Two-way light -duty Disc plow technical data sheet



Model

1LY(SX)-325

1LY(SX)-425

1LY(SX-525)

1LY(SX)-625

Dia of disc

660mm"X6"

660mm"X6"

660mm"X6"

660mm"X6"

Max working width (m)

0.75

1

1.25

1.5

Max working depth(cm)

25-30

25-30

25-30

25-30

NO. of disc

3

4

5

6

Diameter of disc (mm)

650-660

650-660

650-660

650-660

Weight (kg)

520

600

680

780

Matched power (k w.)

≥47

≥58

≥73

≥88

Method of linkage

Type Ⅱ three-point mounted



Please feel free to contact us for more information about two-way light-duty disc plow.
